| Model | a | b | c | d | R | r | h | H | e | F | G | z | B | k | Q |
| T75 | 36 | 31 | 12 | 11 | 14 | 7 | 3 | 7 | 4 | 2.5 | 12 | 3 | 17 | 9 | 6" |
| T89 | 38 | 32 | 13 | 13 | 14 | 8 | 5 | 9 | 4 | 3.5 | 13 | 3 | 19 | 10.5 | 8" |
| T90 | 38 | 36 | 13 | 13 | 16 | 8 | 6 | 10.5 | 4 | 3.5 | 13 | 3 | 19 | 10.5 | 8" |
| T127 | 50 | 51.5 | 18.5 | 17 | 19 | 8 | 6.5 | 13 | 7 | 4.6 | 22 | 5 | 25 | 15 | 6" |
Solid Guide Rail Clips are robust mechanical fasteners used to secure solid-type elevator guide rails—such as T75, T89, T90—to the elevator shaft wall or mounting brackets. These clips provide a stable, vibration-resistant connection between the guide rail and its structural support, ensuring smooth and safe operation of the elevator system.
Designed to match the cross-section and thickness of solid guide rails, these clips are a standard part of elevator installation and are widely used in passenger, freight, and high-rise elevator systems.
Solid guide rail clips are engineered to provide a rigid and reliable connection between solid guide rails and the supporting machine frame. Their design is focused on maintaining positional accuracy, preventing rail movement, and ensuring stable load transfer under dynamic operating conditions. Common structural forms include U-shaped and C-shaped clamps, as well as variants with flanges or reinforcement ribs that enhance stiffness and resistance to deformation. The selection of the clip profile is determined by the guide rail geometry and the required clamping strength, with the clip’s inner surface closely matching the rail’s contour to ensure uniform contact and minimize stress concentration.
The design of the contact surfaces is a critical factor in ensuring long-term stability. Many solid guide rail clips incorporate anti-slip or friction-enhancing features, such as serrated contact faces or textured surfaces, to prevent micro-movements under vibration or cyclic loads. The positioning of mounting holes and the establishment of a stable installation datum are also essential. Properly designed hole patterns ensure accurate alignment and reduce the risk of misalignment during assembly. Additionally, reinforcement features such as gussets, ribs, or thicker sections can be included to improve resistance to bending and torsion, particularly in high-load or high-speed applications. Overall, solid guide rail clips are designed to provide a strong, precise, and durable fastening solution that supports the performance and longevity of linear guidance systems.
According to international standards: ISO7465:2007; ISO630: 2021. According to international standards, conduct comprehensive testing of raw materials based on the material certification provided by suppliers to ensure that the quality of each batch of raw materials meets the requirements.
Configure two automated guide rail production lines. The equipment must ensure that the produced items comply with or exceed customer requirements while maintaining the stability of straightness, distortion, and surface roughness
Given the stringent requirements for straightness and twist in BE grade guideways, specialized automatic straightening and twist correction equipment, along with advanced detection systems, have been implemented. The straightness is maintained within 0.5 mm, while the twist is controlled to within 30' per meter
